| Image Sensor | 1/2.8" CMOS |
| Total Pixels | 2MP |
| Zoom | 10x optical zoom,10x digital zoom, total magnification 100x |
| Shooting Area | A4 and below |
| Focus | Automatic / Manual |
| Resolution | 1920x1080, 1024x768 |
| Horizontal Resolution | ≥1000TV lines |
| Frame rate | 45fps(optional: 30fps) |
| Lamp | LED light with three-level dimming |
| White balance | Automatic |
| Free Software | Visualizer, supports Windows® 7, 10, 11 |
| IR Remote Control | Standard |
| Built-in Mic | Standard |
| Operating Voltage | 12V DC power adapter |
| Input Interface | VGA*1, HDMI*1, Audio*1 |
| Output Interface | VGA*2, HDMI*1, Audio*1, USB2.0 B*1, USB2.0 A*2 |
| Device Dimension | Folding Dimension: 441*220*90mm Unfolding Dimension: 415*220*486mm |
| USB Video Stream Format | Support MJPG, AVI |
| Image Format | Support JPG/BMP |
| Image Storage | Stored on the computer or USB flash drive via PC software (Visualizer). |
| Buttons Function | Power, Sourcing, Lamp, Auto Focus, Zoom in&out, Brightness+-, Rotate, Freeze |
| N.W./G.W. | 4.25kg/5.5±0.5kg |
| Anti-Theft | Mechanism Locker with Keys |
| Features | via Software | via IR Remote |
|---|---|---|
| Annotation | √ | × |
| Snap | √ | √ |
| Recording | √ | × |
| Playback | √ | × |
| Split Screen | √ | × |
| Picture in picture | × | × |
| Freeze | √ | √ |
| Auto focus | √ | √ |
| Zoom In/Out | √ | √ |
| Partial Zoom | × | × |
| Rotation | √ | √ |
| Mirror | × | √ |
| Color/Black and White | √ | √ |
| Brightness+- | √ | √ |
| Text/Picture | √ | √ |
| Sharpness+- | √ | √ |
| Negative | × | √ |
